SKYLAB Skw92A Spi/I2S/I2C 32MB flash 1024Mb RAM DDR2 Openwrt 2T2R Mimo Mtk Mt7628 Iot Wlan Access Point Wifi Module
US $100.00/lot
Recommended Products
Product Description
Name: Skylab Skw92A Spi/I2S/I2C 32MB flash 1024Mb RAM DDR2 Openwrt 2T2R Mimo Mtk Mt7628 Iot Wlan Access Point Wifi Module
Model NO.: SKW92A_E321
The module SKW92A compliant to 802.11 b/g/n Wi-Fi Solution for low power, low-cost, and highly integrated AP and consumer electronic devices, the module requiring only a external 3.3V power supply . The module based on the single chip MT7628N which integrates an 802.11n MAC/BB/radio with internal PA and LNA. It supports 802.11n operations up to 144 Mbps for 20 MHz and 300 Mbps for 40 MHz channel respectively, and IEEE 802.11b/g data rates. The module support AP mode and client mode and router mode. Especially in the IOT, a wide range of applications.
Compliant to IEEE 802.11b/g/n 2T2R Mode with support for a 300Mbps PHY data rate. DDR2 memory up to 1024Mb Flash memory up to 256Mb 4LAN ports and 1WAN port Support USB 2.0 host device Support USB disk. Support AP/Client/Router mode Security: WEP 64/128, WPA, WPA2, TKIP, AES, WAPI RoHS compliance meets 50(L) x 25(W) x 3.0(H) mm small dimension
Dimension: 50(L) x 25(W) x 3.0(H) mm
Product Specifications
- GPS type Receiver & Antenna
- Brand Name SKYLAB
- Model Name SKW92A
- Name 2x2 mimo WLAN wifi module
- DDR2 512Mb
- flash 128Mb
- ports 4 LAN and 1 WAN
- Mode AP/AP client/Router mode
- Dimension 50(L) x 25(W) x 3.0(H) mm
- Chip MT7628N
- Antenna Type IPEX
- Supply USB 2.0 host device
- Compliant to openWRT
